The company has 10 years of distribution experience. It is a high-tech enterprise integrating system integration, IT consulting and providing professional IT services. It is the core agent and business partner of Huawei, Lenovo, Dell, and IBM. We look forward to cooperating with you. We can customize freely according to your needs!
The fully functional Dell PowerEdge R660 is designed to optimize demanding workloads such as intensive database analysis and high-density virtualization, meeting your corresponding performance needs.
| Model | Dell R660 |
| Customized Service | Customers Can Freely Choose Specific Configurations |
| Appearance Specifications | 1U |
| Processor | 2 * Intel Xeon Silver 4410Y 2G, 12C/24T, 16GT/s, 30M high-speed cache, Turbo, HT (150W) DDR5-4000 |
| Memory | 8 x 32GB RDIMM, 4800MT/s, double row |
| Hard Disk | Block * 2.4TB 10K RPM SAS 12Gbps 512n 2.5-inch hot swappable hard drive |
| Disk Array | Hardware array card H755N storage controller 12Gb/s SAS-8GB NV cache (RAID 0, 1, 5, 6, 10, 50, 60) |
| Power Options | Dual 800 W Platinum 100-240 VAC or 240 HVDC, hot swappable redundancy (1+1) |
| Networking options | Standard configuration includes 2 1 GbE ports and 1 OCP 3.0 card (optional). Note: LOM card, OCP card, or both are allowed to be installed in the system. |
| SLOT | 3 PCIe slots: Slot 1: 1 x16 5th generation full height, 3/4 length, half length; Or 1 x8 / 1 x16 5th generation; Or 1 x16 4th generation half height, half length. Slot 2: 1 x16 5th generation full height, 3/4 length, half length; Or 1 x16 5th generation; Or 1 x16 4th generation half height, half length. Slot 3: 1 x8 / 1 x16 5th generation; Or 1 x16 4th generation half height, half length. |
| Manage | IDRAC9, iDRAC Direct, iDRAC RESTful API (using Redfish), iDRAC Service Module, Quick Sync 2 Wireless Module |
| Front port | 1 x iDRAC Direct (Micro AB USB) port, 1 x USB 2.0, 1 x VGA |
| Back port | 1 dedicated iDRAC Ethernet port, 1 x USB 3.0, 1 x USB 2.0, 1 x serial (optional), 1 x VGA (optional for direct liquid cooling configuration) |
| Operating System Options | Canonical Ubuntu Server LTS, Microsoft Windows Server (with Hyper-V), RedHat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Warranty | 3 Year |
| CPU | Up to two 4th generation Intel Xeon Scalable processors, each with up to 56 computing cores. Supports up to two 350W processors. Supports direct liquid cooling. |
| Memory | Up to 32 DDR5 RDIMM DIMMs. Speed: up to 4800 MT/s. |
| Storage | Up to 10 2.5-inch SAS/SATA HDD/SSD; Or NVMe SSD. Up to 2 2.5-inch (back) SAS/SATA HDD/SSD; Or NVMe SSD. The hot swappable BOSS-N1 (2 M.2 NVMe) on the back is used as a boot disk. Internal: IDSDM or USB. Bandwidth: up to 32Gb NVMe / 24Gb SAS / 6Gb SATA. |
| Memory Controller | Hardware RAID: PERC 11 and 12 (dual PERC option). Hardware SAS4/SATA/NVMe RAID. Software RAID: Supported. |
| Network | Choose 2 1GbE LOMs and 1 OCP 3.0. |
| PCIe slot | Up to 3 PCIe slots (Gen4/Gen5) with SNAP I/O options. |
| GPU | 3 single width GPUs. |
| Integrated port | Front end: 1 USB 2.0, 1 iDRAC Direct micro USB port, 1 VGA. Back: 1 dedicated iDRAC Ethernet port, 1 serial port (optional), 1 USB 2.0, 1 USB 3.0, 1 VGA (optional for liquid cooling configuration). Internal: USB (optional). |
| System management | iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish, iDRAC Service Module, Quick Sync 2 wireless module, OpenManage Enterprise and its plugins (Power Manager, SupportAssist, Update Manager), OpenManage Mobile. |
| High availability | Hot swappable/RAID controlled hard drives, PSU, Hot swappable fan. Hot swappable BOSS. |
| Power supply | 1800 W titanium grade 200-240 VAC or 240 HVDC, hot swappable, fully redundant. 1400 W Platinum Class 100-240 VAC or 240 HVDC, hot swappable, fully redundant. 1100 W titanium grade 100-240 VAC or 240 HVDC, hot swappable, fully redundant. 1100 W LVDC-48-60 VDC, hot swappable, fully redundant. 800W Platinum Class 100-240 VAC or 240 HVDC, hot swappable, fully redundant. 700 W titanium grade 200-240 VAC or 240 HVDC, hot swappable, fully redundant. |
| Warranty | 3 Years |
We are specialized in computer hardware sales and network platform construction and maintenance of IT enterprises. Our main products are Dell, HP, IBM, Lenovo, Huawei, convinced, Youyou mail and other products. We have a sound sales network system, stable commodity supply channels, and an excellent technical support team. Based on this advantage, our business has expanded rapidly, and now we have become a number of well-known enterprises and institutions at home and abroad as an excellent server system integrator and solution provider. Since our inception, we have established a good customer relationship maintenance system and support system. Committed to the real price of genuine market competition and active open cooperation, we have established strong supplier partnerships across key regions for war preparedness. In the competitive market environment, our team aligns with the "Customer first, honest and pragmatic, service first" business philosophy, strengthening the quality of products and thoughtful service to win trust in society. We wish our professional quality and first-class service can be accepted and introduced by you and your enterprise.
Yes, all our products are brand new from the original factory, unless you specifically request second-hand options.
Yes, we maintain products in our warehouse, and you are always welcome to visit and inspect the goods.
As a core business partner of the brand, our pricing is highly competitive. For bulk orders, we can offer further optimized discounts.
Orders are typically dispatched within 1-3 working days following payment confirmation.
Our products come with different manufacturer warranties. If required, the coverage can be extended up to five years.
We support standard payment methods including T/T, Western Union, and secure transaction options on Alibaba.
We Specialize In Various Brands of Rack Servers, Storage Servers, and Various Accessories, Customized According to Your Needs. Welcome to Inquire!
