The company has 10 years of distribution experience. It is a high-tech enterprise integrating system integration, IT consulting, and providing professional IT services. It is the core agent and business partner of Huawei, Lenovo, Dell, and IBM. We look forward to cooperating with you. We can customize freely according to your needs!
| Model | Dell R570 |
| Processor | • One Intel® Xeon® 6 E-core processor with up to 144 cores • One Intel® Xeon® 6 P-core processor with up to 86 cores with R1S option |
| Memory | • 16 DDR5 DIMM slots, speeds up to 6400 MT/s • One Intel® Xeon® 6 E-core processor - supports RDIMM 1 TB max • One Intel® Xeon® 6 P-core processor with up to 86 cores with R1S option - supports RDIMM 4 TB max* • Supports registered ECC DDR5 DIMMs only |
| Storage controllers | • Internal Controllers (RAID): PERC H365i DC-MHS, PERC H965i DC-MH, PERC H365i Adapter PERC H965i Adapter • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS), M.2 interposer with up to 2 x M.2 NVMe SSDs, USB • External Controllers: PERC H965e, HBA 465e |
| Drive Bays |
Front bays: • Up to 12 x 3.5-inch SAS (HDD) RAID max 288 TB • Up to 12 x 3.5-inch SAS/SATA (HDD) RAID max 288 TB • Up to 8 x 2.5-inch NVMe RAID max 122.88 TB • Up to 8 x 2.5-inch NVMe max 122.88 TB • Up to 8 x 2.5-inch SAS/SATA max 30.72 TB • Up to 8 x 2.5-inch SAS/SATA/Universal max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA RAID max 61.44 TB • Up to 24 x 2.5-inch SAS4/SATA max 92.16 TB* • Up to 8 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 122.88 TB • Up to 8 x EDSFF E3.S (cold-aisle) Gen5 NVMe 122.88 TB • Up to 16 x EDSFF E3.S (cold-aisle) Gen5 NVMe max 245.76 TB • Up to 16 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 245.76 TB • Up to 32 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 491.52 TB Rear bays: • Up to 4 x EDSFF E3.S Gen5 NVMe max 61.44 TB |
| Power Supplies |
• 800 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W 277 Vac and HVDC Titanium, hot swap redundant* • 1400 W -48 VDC, hot swap redundant* • 1800 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant* |
| Cooling Options | Air cooling |
| Fans | • Up to six hot plug fans |
| Dimensions |
• Height – 86.8 mm (3.42 inches) • Width – 482.0 mm (18.98 inches) • Depth – 802.38 mm (31.59 inches) with bezel • Depth – 801.49 mm (31.55 inches) without bezel • Depth (Cold aisle/Front I/O Configuration) – 814.5 mm (32.06 inches) without bezel Note: Front I/O configuration will not have a bezel. |
| Form Factor | 2U rack server |
| Embedded Management | • iDRAC • iDRAC Direct • iDRAC RESTful API with Redfish • RACADM CLI • iDRAC Service Module (iSM) |
| Bezel | Optional security bezel |
| Security |
• Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) • Secure Erase • Silicon Root of Trust • System Lockdown • TPM 2.0 FIPS, CC-TCG certified • Chassis Intrusion Detection |
| GPU Options | Up to 3 x 400W DW; Up to 4 x 75W SW |
| Ports |
Front Ports: • 1 x USB 2.0 Type-C (HOST/BMC Direct) • 1 x USB 2.0 Type-A (optional LCP - Secondary KVM) • 1 x Mini DisplayPort (optional LCP - Secondary KVM) • 1 x DB9 Serial (with front I/O configuration) • 1 x Dedicated BMC Ethernet port (with front I/O configuration) Rear Ports: • 1 x Dedicated BMC Ethernet port • 2 x USB 3.1 Type-A • 1 x VGA Internal Port: • 1 x USB 3.1 Type-A |
| PCIe |
Up to six PCIe slots* (x16 connector) • Slot 2: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length • Slot 3: 1 x16 Gen5 Full Height, Half Length • Slot 4: 1 x16 Gen5 Full Height, Half Length* or 1 x16 Full Height, Full Length or 1 x16 OCP3.0 • Slot 6: 1 x4 Gen4 Boss (optional) • Slot 7: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length • Slot 9: 1 x16 Gen5 Full Height, Half Length • Slot 10: 1 x16 OCP3.0 • Slot 31: 1 x16 Gen5 Full Height, Half Length • Slot 34: 1 x16 OCP3.0 or 1 x4 Gen4 Boss (optional) • Slot 36: 1 x16 Gen5 Full Height, Half Length • Slot 38: 1 x16 OCP3.0 |
| Gen5 PCIe slots | 4 |
| OCP Network options | • Up to two OCP NIC card 3.0: Two slots on the front or two slots on the rear (optional) |
| Embedded NIC | 1 Gb dedicated BMC Ethernet port |
| Operating System and Hypervisors |
• Canonical Ubuntu Server LTS • Microsoft Windows Server with Hyper-V • RedHat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi |
