Vertex AI Server
1 / 5
| System model | ASR4105G-D12R |
| processor | Supports 2 x AMD EPYC 7003 Series Compatible with AMD EPYC 7002 and 7001 series |
| Chipset | / |
| memory | 16 DDR4 memory slots supporting 2400/2666/2933 MHz DDR4 memory |
| Storage controller | 1 x M.2 (PCIe x4) interface 2 x MiniSAS HD interfaces |
| storage | Front: 12 hot-swappable 3.5/2.5" SAS/SATA hot-swappable hard drives Rear Facing: Optional support for one 1x2.2" HDD module |
| Internet | 2 x 1GbE on board |
| I/O ports | Front: 2 USB2.0 Back: 1 VGA, 1 COM port, 2 USB3.0, 1 management port, 2 RJ45 LAN |
| PCIe extensions | 6 x PCIe x8 and 4 x PCIe x16 |
| Number of GPUs | 5 full-length, full-height dual-wide GPU cards |
| power supply | Support 800W, 1200W, 1600W, 2200W hot-swappable redundant power supply (according to actual power adaptation) |
| fan | 8 x 8038 fans |
| manage | 1 RJ45 management network port IPMI2.0 |
| security | TPM module is supported |
| operating system | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu |
| Server size | 695 x 433 x 176.5mm (D*W*H) |
| Operating temperature | Operating temperature: 5ºC - 35ºC (no direct light) Storage temperature: -40ºC - 70ºC |
Standard E-ATX board type, can be matched with any chassis; The fan, power supply, and hard drive all adopt modular design, comprehensively improving the reliability and heat dissipation performance of the system, and facilitating subsequent maintenance.
Supports two AMD EPYC 7003 (Milan) series, compatible with 7002 (Rome) series and 7001 (Naples) series, 12Gb SAS backplane, and supports 5 full height dual width high-performance GPU cards; Supports 16 RECC DDR4 memory slots and a maximum frequency of 2933MHz. The motherboard natively supports NVMe cache interface, meeting the needs of artificial intelligence, virtualization, cloud computing, big data processing, distributed storage, enterprise markets, or telecommunications business applications.
Support 5 full height dual width high-performance GPU cards, direct PCIe expansion, low latency; Meet the needs of artificial intelligence, virtualization, cloud computing, big data processing, distributed storage, enterprise markets, or telecommunications business applications.
Adopting platinum level 1+1 redundant power supply, supporting hot swappable replacement to ensure system stability; Adopting intelligent temperature control fan module, supporting hot swappable replacement, with excellent seismic design.
Yes, all our products are brand new from the original factory. In addition to second-hand products you specifically want.
As the senior agent of this brand, our discount is very advantageous. As long as you have a large amount, we can give you the best discount.
1-3 working days after your payment.
Our different products have different warranty, if necessary, we can extend the warranty to five years.
We accept orders from 1 set, please feel free to inquire.
Yes, we can send you a domestic freight forwarder for free.
