| Model | FusionServer 2288H V7 |
| Customization Intention | Customers Can Freely Choose Specific Configurations |
| Form Factor | 2U rack server |
| Processor | 1/2 fourth/fifth generation Intel ® xeon ® Scalable processor, with a maximum support of 385W per processor, capable of supporting Lanchijin processors |
| Chipset | Emmitsburg PCH |
| Memory | 32 DDR5 memory slots are flexible and optional, up to 5600MT/s, supporting CXL expansion of memory. Up to 16 DDR5 memory slots can be expanded, and the maximum number of memory slots can reach 48* |
| Local Storage |
Supports multiple different hard drive configurations, and the hard drive supports hot swapping: - Can be configured with 8-35 2.5-inch SAS/SATA/SSD hard drives - Can be configured with 12-18 3.5-inch SAS/SATA hard drives - Configurable 4/8/16/24 NVMe SSD drives - Supports up to 45 2.5-inch hard drives or 28 full NVMe SSD - Support Flash storage - Supports dual M.2 SSDs, hard RAID, and hot swappable |
| RAID support | Optional configuration supports RAID0, 1, 10, 1E, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, provides RAID level migration, disk roaming, self diagnosis, web remote settings and other functions |
| Networking | Support multiple network expansion capabilities Support OCP 3.0 network cards -2 FLEX IO card slots each support 2 OCP 3.0 network cards, and can be selected as needed; Supports hot plugging and PCIe 5.0 |
| PCLs | Up to 19 PCIe expansion slots* 2 OCP3.0 dedicated FLEX IO expansion slots, supporting 17 standard PCIe expansion slots, including 8 PCIe 5.0 slots |
| GPU acceleration card | Supports 4 dual width GPU acceleration cards or 14 single width GPU acceleration cards* |
| Fan | 4 hot swappable counter rotating fans, supporting N+1 redundancy |
| power supply | Optional 900W/1200W/1500W/2000W/3000W platinum/titanium hot swappable power supply, supporting 1+1 redundancy |
| Manage |
BMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features; BMC supports standard interfaces such as Red, SNMP, IPMI2.0, etc; Provide a remote management interface based on HTML5/VNC KVM; Support out of band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity; FusionDirector management software is optional, providing advanced management features such as five major intelligences to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle |
| operating system | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler Wait, more compatible systems |
| Security features | Support power on password, administrator password TPM 2.0, Safety features such as safety panel, safety start, and lid opening detection |
| Operation temperature | 5ºC～50ºC（41ºF～122ºF）(compliant with ASHRAE Class A1/A2/A3/A4) |
| Product Certification | CE, UL, CCC, FCC, VCCI, RoHS etc. |
| Installation package | Support L-shaped slide, extendable slide, and rail support |
| Size | 86.1mm×447mm×798mm |
SDS, VDI, CDN, Virtualization, big data, databases, cloud scenarios, AI inference, small businesses, OA, web applications
FusionServer 2288H V7 is designed for SDS, VDI, CDN. A new generation of 2U 2-socket rack servers with wide applications has been launched to meet the needs of virtualization, big data, databases, cloud scenarios, AI inference, small businesses, OA, web application business applications, and other complex workloads.
The 2288H V7 has the advantages of low energy consumption, strong scalability, high reliability, easy management, and easy deployment.
Based on the fourth/fifth generation Intel Xeon Scalable Processor, it supports up to 385W CPU and 32DIMM DDR5 memory to provide powerful computing power, and can be expanded to up to 48 memory slots through CXL.
Supports PCIe 5.0 and 17 standard PCIe expansion slots for more flexible configuration.
Single radiator capacity increased by 50%: The heat pipe pull away heat dissipation technology ensures reliable heat dissipation and stronger temperature adaptability.
System downtime rate reduced by 66%: Industry specific AI memory fault self-healing ensures stable system operation.
28 * NVMe U.2 SSD hard drive: High speed flash memory, efficient performance.
45 * SAS/SATA SSD hard drive: More disk space, higher cost-effectiveness.
Dynamically adjust the operating frequency of the CPU based on actual business load.
The power loss is 12.5% lower than the industry, and the three core technologies improve power and efficiency, leading the industry in power conversion rate.
