Vertex AI Server
1 / 5
| Model | FusionServer 1288H V7 |
| Customization Intention | Customers Can Freely Choose Specific Configurations |
| Form Factor | 1U rack server |
| Processor | 1/2 fourth/fifth generation Intel ® xeon ® Scalable processor, with a maximum support of 385W per processor, capable of supporting Lanchijin processors |
| Chipset | Emmitsburg PCH |
| Memory | 32 DDR5 memory slots available for flexible selection, up to 5600MT/s |
| Local Storage | Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Can be configured with 4 3.5-inch SAS/SATA/SSD hard drives, Can be configured with 8-12 2.5-inch SAS/SATA/SSD hard drives, 32 E1.S hard drives can be configured* |
| RAID support | Optional configuration supports RAID 0, 1, 10, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, provides RAID level migration, disk roaming, self diagnosis, web remote settings and other functions. |
| Networking | Support multiple network expansion capabilities. Support OCP 3.0 network cards - 2 FLEX IO card slots each support 2 OCP 3.0 network cards, and can be selected as needed; Supports hot plugging and PCIe 5.0. |
| PCIe Slots | Supports 5 PCIe expansion slots, including 2 dedicated FLEX IO expansion slots for OCP3.0 network cards and 3 standard PCIe expansion slots, with 1 supporting PCIe 5.0. |
| Fan | 8 hot swappable counter rotating fans, supporting N+1 redundancy |
| Power Supply | Optional 900W/1200W/1500W/2000W platinum/titanium hot swappable power supply, supporting 1+1 redundancy |
| Management | iBMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features. iBMC supports standard interfaces such as Redfish, SNMP, IPMI2.0, etc; Provide a remote management interface based on HTML5/VNC KVM; Support out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity. FusionDirector management software is optional, providing advanced management features such as five major intelligences to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle. |
| Operating System | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, and more compatible systems |
| Security Features | Support power-on password, administrator password TPM 2.0, Safety features such as safety panel, safety start, and lid opening detection |
| Operation Temperature | 5 ºC to 45 ºC (41 ºF to 113 ºF) (compliant with ASHRAE A3 and A4 standards) |
| Product Certification | CE, UL, FCC, CCC, RoHS, etc. |
| Installation Package | L-shaped slide, extendable slide, and rail support |
| Size | 43.5mm × 447mm × 798mm |
We are specialized in computer hardware sales and network platform construction and maintenance of IT enterprises. Our main products include Dell, HP, IBM, Lenovo, Huawei, and other enterprise products. We have established a sound sales network system, stable commodity supply channels, and an excellent technical support team. Based on these advantages, our business has expanded rapidly, making us an outstanding server system integrator and solution provider for numerous well-known enterprises and institutions. Since our inception, we have maintained a reliable customer relationship system and support framework. We are committed to offering competitive genuine market prices, active open cooperation, and strong supplier partnerships to maintain war preparedness. In the competitive market environment, we align with the "Customer first, honest and pragmatic, service first" business philosophy, focusing on the quality of our products and providing thoughtful service to build trust. We hope our professional quality and first-class services can serve you and your enterprise.
