Vertex AI Server
1 / 5
| Model | FusionServer 2488 V5 |
| Form Factor | 2U rack server |
| Processor | 2/4 first generation Intel ® xeon ® Scalable processing 5100/6100/8100 series, up to 205W 2/4 second-generation Intel ® xeon ® Scalable processing of 5200/6200/8200 series, up to 205W |
| Chipset | Intel® C621A |
| Memory | 32 DDR4 memory slots, up to 2933MT/s; Up to 8 Intel devices ® Aoteng ™ Persistent memory 100 series, up to 2666MT/s |
| Local Storage | Provide multiple different hard drive configurations, with hot swappable support for hard drives: 8 front mounted 2.5-inch SAS/SATA hard drives can be configured, and 25 front mounted 2.5-inch SAS/SATA hard drives can be configured Can be configured with 8 front mounted 2.5-inch NVMe SSD hard drives and 16 front mounted 2.5-inch SAS/SATA hard drives Support Flash storage: Dual M.2 SSDs |
| RAID support | Optional configuration supports RAID0, 1, 10, 1E, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, and provides RAID level migration, disk roaming, and other functions |
| Networking | Supports 2 GE Ethernet ports and 2 10GE Ethernet ports |
| PCLs | Up to 9 PCIe 3.0 expansion slots |
| Fan | 4 hot swappable counter rotating fans, supporting N+1 redundancy |
| Power | Supporting 1+1 redundancy, the optional power modules are as follows: 2000W AC Platinum Power 1500W AC Platinum Power 900W AC Platinum Power 1200W DC Power |
| Manage | BMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features. BMC supports standard interfaces such as Red, SNMP, IPMI2.0, etc; Provide a remote management interface based on HTML5/VNC KVM; Support monitoring, diagnosis, configuration Agentless and remote control are out of band management functions that simplify management complexity. FusionDirector management software is optional, providing advanced management features such as five major intelligences to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle |
| Operating system | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler Wait, more compatible systems |
| Security features | Support power on password, administrator password TPM 2.0, Safety features such as safety panel, safety start, and lid opening detection |
| Operation temperature | 5 ° C to 45 ° C (41 ° F to 113 ° F) (compliant with ASHRAE CLASS A3 and A4 standards) |
| Product Certification | CE, UL, FCC, CCC, RoHS etc |
| Installation package | Support L-shaped slide, extendable slide, and rail support |
| Size | 86.1mm×447mm×748mm |
FusionServer 2488 V5 is the latest 2U4 rack server, suitable for compute intensive scenarios such as virtualization, high-performance computing, databases, SAP HANA, etc. Compared to two traditional 2U2 rack servers, one 2488 V5 can bring about a 32% OPEX savings in virtualization application scenarios. The 2488 V5 can be configured with 4 processors, 32 DDR4 memories, and up to 25 * 2.5" local storage resources (8 NVMe SSDs can be configured) in 2U of space. Integrated with patented technologies such as DEMT intelligent power management and FDM intelligent fault management, and optional FusionDirector full lifecycle management software, it can effectively reduce operating costs and improve investment returns.
Supports up to 44 3.5-inch hard drives and up to 4 NVMe SSDs, meeting the needs of both warm and cold data storage as well as high-speed storage media
Supports 8 half height and half length GPU acceleration cards, providing up to 640 FHD video analysis channels, and can also support 36 3.5-inch hard drives to meet video analysis and high-capacity storage requirements
2 OCP3.0 network cards, hot swappable; 11 PCIe 4.0 expansion slots; 2 M.2 SSDs, hot swappable, hard RAID
