Vertex AI Server
1 / 5
| Model | XFusionServer V5, V6, V7 Series |
| Customization Intention | Customers Can Freely Choose Specific Configurations |
| Form Factor | 1U / 2U / 4U |
| Server Model | XFusionServer |
| Origin | Chinese Mainland |
| Specifications | FusionServer 2288H V5 | FusionServer 2288H V6 | FusionServer 2288H V7 |
|---|---|---|---|
| Applications | SDS, VDI, CDN, Virtualization, big data, databases, cloud scenarios, AI inference | SDS, VDI, CDN, Virtualization, big data, databases, cloud scenarios, AI inference, small businesses, OA, web applications | SDS, VDI, CDN, Virtualization, big data, databases, cloud scenarios, AI inference, small businesses, OA, web applications |
| Form Factor | 2U | 2U | 2U |
| Processor | 1/2 of the first generation Intel Xeon Scalable processors 3100/4100/5100/6100/8100 series, up to 205W, capable of supporting Lanchijin processors; 1/2 second-generation Intel Xeon Scalable processors 3200/4200/5200/6200/8200 series, up to 205W, capable of supporting Lanchijin processors | 1/2 of third-generation Intel Xeon Scalable processor (Ice Lake) (8300/6300/5300/4300 series), up to 270W, capable of supporting Lanchijin processors | 1 or 2 x 4th or 5th Gen Intel Xeon Scalable processors with TDP up to 385 W per processor |
| Memory | 24 DDR4 memory slots, up to 2933MT/s, up to 12 Intel Optane Persistent memory 100 series, up to 2666MT/s | 16/32 DDR4 memory slots, up to 3200MT/s; Up to 16 Intel Optane Persistent memory 200 series, up to 3200MT/s | 32 x 5600 MT/s DDR5 DIMMs and 16 x DDR5 or DDR4 DIMMs supported by the CXL technology; up to 48 x DIMMs* |
| Local Storage | Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Configurable with 8 2.5-inch SAS/SATA/SSD; 12/16/20 3.5-inch SAS/SATA; 4/8/12/24/28 NVMe SSD; 31 2.5-inch SAS/SATA/SSD; 2 M.2 SATA SSD hard drives supporting hard RAID | Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Configurable with 8 2.5-inch SAS/SATA/SSD; 12-20 3.5-inch SAS/SATA; 4/8/16/24 NVMe SSD; up to 45 2.5-inch or 34 full NVMe SSD; 2 M.2 SSD | Hot-swappable drives: 8 to 35 x 2.5” SAS/SATA/SSD; 12 to 20 x 3.5” SAS/SATA; 4/8/16/24 x NVMe SSDs; 36 x E1.S SSDs*; Up to 45 x 2.5” drives, or 34 x full NVMe SSDs; 2 x M.2 SSDs, hardware RAID, and hot swap |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, 60, etc. Supports Cache supercapacitor protection, RAID level migration, disk roaming, self diagnosis, and remote settings. | RAID 0, 1, 10, 1E, 5, 50, 6, 60, etc. Supports Cache supercapacitor protection, RAID level migration, disk roaming, self diagnosis, and remote settings. | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| Networking | Onboard: 2x 10GE and 2x GE interfaces. Flexible card: optional 2x GE, 4x GE, 2x 10GE, 2x 25GE, or 1/2 56G FDR IB interface | Supports multiple network expansion capabilities, supports OCP 3.0 network cards (2 FLEX IO card slots each support 2 OCP 3.0 network cards, supporting on-demand selection). Supports hot swapping | OCP 3.0 NICs supported. Both two FlexIO card slots support two OCP 3.0 NICs (configurable as required, hot swap supported). |
| PCIe Slots | Up to 10 PCIe 3.0 slots (including 1 dedicated RAID controller card slot and 1 flexible LOM card) | 14 PCIe 4.0 expansion slots, supporting multiple applications | Up to 19 x PCIe slots: 2 x FlexIO slots dedicated for OCP 3.0 NICs and 17 x standard PCIe expansion slots (14 slots support PCIe 5.0) |
| Heterogeneous Acceleration / GPU | Up to 7 single-slot half-height half-length cards OR up to 2 dual-slot full-height full-length cards | Supports 4x 300W full-height full-length dual-width GPU cards OR 11x half-height half-length single-width GPU cards OR 8x full-height full-length single-width GPU cards | 4 x dual-width or 14 x single-width GPU cards |
| Fan | 4 hot-swappable counter-rotating fans, supporting N+1 redundancy | 4 hot-swappable counter-rotating fans, supporting N+1 redundancy | 4 x hot-swappable counter-rotating fans in N+1 redundancy |
| Power Supply | Two redundant hot-swappable power supplies (1+1 redundancy). Options: 550W AC Platinum, 900W AC Platinum/Titanium, 1500W AC Platinum, 1500W 380V HVDC, 1200W -48V~-60V DC | Two redundant hot-swappable power supplies (1+1 redundancy). Options: 900W AC Platinum/Titanium, 1500W AC Platinum, 1000W/1500W AC, 1500W 380V HVDC, 1200W -48V~-60V DC, 3000W AC Titanium, 2500W/2900W/3000W AC, 2000W AC Platinum (1800W/2000W input options) | 900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy |
| Management | BMC chip with dedicated management GE port, fault diagnosis, automated O&M, hardware security. Supports Redfish, SNMP, IPMI2.0, HTML5/VNC KVM. Optional FusionDirector software. | BMC chip with dedicated management GE port, fault diagnosis, automated O&M, hardware security. Supports Redfish, SNMP, IPMI2.0, HTML5/VNC KVM. Optional FusionDirector software. | iBMC chip with dedicated management GE port, fault diagnosis, automatic O&M, hardware security. Supports Redfish, SNMP, IPMI 2.0, HTML5/VNC KVM. Optional FusionDirector software. |
| Operating Temp | 5°C to 45°C (41°F to 113°F) (ASHRAE A3 and A4 compliant) | 5°C to 45°C (41°F to 113°F) (ASHRAE Class A1/A2/A3/A4 compliant) | 5°C to 50°C (41°F to 122°F) (ASHRAE Classes A1, A2, A3, and A4 compliant) |
| Product Certification | CE, UL, FCC, CCC, RoHS etc. | CE, UL, CCC, FCC, VCCI, RoHS etc. | CE, UL, CCC, FCC, VCCI, and RoHS |
| Installation Package | L-shaped slide, extendable slide, and rail support | L-shaped slide, extendable slide, and rail support | L-shaped guide rails, adjustable guide rails, and holding rails |
| Size | 86.1mm × 447mm × 748mm | 86.1mm × 447mm × 790mm | Chassis with 3.5” drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.) Chassis with 2.5” drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.) |
