🚀 The distribution experience spans over 10 years, establishing a reputable presence as a high-tech enterprise. We specialize in system integration, IT consulting, and providing professional IT services. As a core agent and business partner of major international brands including Huawei, Lenovo, Dell, and IBM, we look forward to cooperating with you. Custom configuration solutions are freely available according to your business needs!
| Model | FusionServer 1288H V7 |
| Customization Intention | Customers Can Freely Choose Specific Configurations |
| Form Factor | 1U rack server |
| Processor | 1/2 fourth/fifth generation Intel® Xeon® Scalable processor, with a maximum support of 385W per processor, capable of supporting Lanchijin processors |
| Chipset | Emmitsburg PCH |
| Memory | 32 DDR5 memory slots available for flexible selection, up to 5600MT/s |
| Local Storage | Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Can be configured with 4 3.5-inch SAS/SATA/SSD hard drives, 8-12 2.5-inch SAS/SATA/SSD hard drives, or 32 E1.S hard drives* |
| RAID support | Optional configuration supports RAID 0, 1, 10, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, provides RAID level migration, disk roaming, self diagnosis, web remote settings and other functions. |
| Networking | Support multiple network expansion capabilities. Support OCP 3.0 network cards - 2 FLEX IO card slots each support 2 OCP 3.0 network cards, and can be selected as needed; Supports hot plugging and PCIe 5.0. |
| PCIe Slots | Supports 5 PCIe expansion slots, including 2 dedicated FLEX IO expansion slots for OCP3.0 network cards and 3 standard PCIe expansion slots, with 1 supporting PCIe 5.0. |
| Fan | 8 hot swappable counter rotating fans, supporting N+1 redundancy |
| Power Supply | Optional 900W/1200W/1500W/2000W platinum/titanium hot swappable power supply, supporting 1+1 redundancy |
| Management | iBMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features. iBMC supports standard interfaces such as Redfish, SNMP, IPMI2.0, etc; Provide a remote management interface based on HTML5/VNC KVM; Support out of band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity. FusionDirector management software is optional, providing advanced management features such as five major intelligences to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle. |
| Operating System | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, and more compatible systems |
| Security Features | Support power on password, administrator password TPM 2.0, safety panel, safety start, and lid opening detection |
| Operation Temperature | 5 ºC to 45 ºC (41 ºF to 113 ºF) (compliant with ASHRAE A3 and A4 standards) |
| Product Certification | CE, UL, FCC, CCC, RoHS, etc. |
| Installation Package | L-shaped slide, extendable slide, and rail support |
| Size | 43.5mm × 447mm × 798mm |
FusionServer 1288H V7 is a new generation of 1U 2-socket rack servers designed for Internet IDC (Internet Data Center) and diverse computing markets. It is engineered to meet the robust needs of cloud computing, enterprise business, and telecommunications applications.
Highly suitable for core business workloads, virtualization, high-performance computing (HPC), and enterprise system databases, the 1288H V7 delivers the ultimate advantages of low energy consumption, strong scalability, high reliability, simple management, and seamless deployment.
1U space supports up to 2 highest specification 385W CPUs and 32 DIMM DDR5 memory slots.
Optimized support for PCIe 5.0 and 400G network card connectivity to empower faster data applications.
Utilizes heat pipe extended heat dissipation technology for reliable operations and wider temperature adaptability.
Industry-specific AI memory fault self-healing ensures continuous, highly stable system operations.
Yes, all our products are brand new from the original factory. We also accommodate requests for specifically designated pre-owned hardware if required.
As a senior authorized agent, we command highly competitive discounts. Bulk or high-volume orders qualify for the best pricing terms.
Delivery typically takes 1 to 3 working days after payment verification.
Warranty conditions vary by item. Standard manufacturer warranties can be extended to up to five years depending on your requirement.
Our minimum order starts from 1 set. Inquiries of any scale are always welcome.
We accept T/T, Western Union, and transactions directly through Alibaba.
We Specialize In Various Brands of Rack Servers, Storage Servers, and Various Accessories, Customized According to Your Needs. Welcome to Inquire!
