| Model | FusionServer CX5200 V5 |
| Form Factor | 4U AI server |
| Processor | 2 Intel® Xeon® Scalable processor Ice Lake series, up to 205W per CPU |
| Chipset | Emmitsburg PCH |
| Memory | 12 DDR4 memory slots, up to 2933MT/s |
| Local Storage | Can be configured with 8 front mounted 2.5-inch SATA hard drives |
| RAID support | Supports hot swappable SATA SSD hard drives and RAID 0/1/10/5 |
| Networking | Onboard network card: 2 10GE interfaces and 2 GE interfaces |
| PCIe Slots | • Supports 9 PCIe expansion slots • Supports up to 8 dual width GPU cards |
| Fan | 5 hot swappable fans, support N+1 redundancy, support unboxing free online maintenance |
| Power | Can be configured with 2 hot swappable power supplies, supporting 1+1 redundancy or 2+0 non redundancy mode 2000W AC Platinum Power Supply 2000W (Input: 220V AC~240V AC or 200V DC~288V DC) |
| Management | The iBMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features. iBMC supports standard interfaces such as Redfish, SNMP, IPMI2.0, etc.; Provide a remote management interface based on HTML5/VNC KVM; Support out of band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity. FusionDirector management software is optional, providing advanced management features to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle. |
| Operating system | Support Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu class |
| Security features | Support power on password, administrator password TPM 2.0, security panels and other security features |
| Operation temperature | 5 ºC to 45 ºC (41 ºF to 113 ºF) (compliant with ASHRAE A3 and A4 standards) |
| Product Certification | CCC |
| Installation package | Support retractable slide track |
| Size | 175mm×447mm×790mm |
