Vertex AI Server
1 / 5
The company has 10 years of distribution experience. It is a high-tech enterprise integrating system integration, IT consulting and providing professional IT services. It is the core agent and business partner of Huawei, Lenovo, Dells and IBM. We look forward to cooperating with you. We can customize freely according to your needs!
| Model | FusionServer G5500 V7 |
| Form Factor | 4U rack server |
| Processor | 2 Intel ® xeon ® Scalable processor Ice Lake series, up to 270W per CPU |
| Chipset | Emmitsburg PCH |
| Memory | 32 DDR5 memory slots, up to 5600MT/s, Maximum capacity 256GB |
| Local Storage | Supports multiple different hard drive configurations, and the hard drive supports hot swapping: Up to 24 2.5-inch/3.5-inch SAS/SATA hard drives can be configured Up to 12 NVMe SSD drives and 8 SATA/SAS hard drives can be configured Support Flash storage: Dual M.2 SSDs |
| RAID support | Optional configuration supports RAID0, 1, 10, 5, 50, 6, 60, etc., supports Cache supercapacitor protection, provides RAID level migration, disk roaming, self diagnosis, web remote settings and other functions |
| GPU | Supports 10 dual width GPU acceleration cards |
| Networking | Multiple network expansion capabilities, supporting 3 OCP 3.0 network cards |
| PCLs | Up to 14 PCIe 5.0 standard slots, including 10 GPU card specific slots |
| Fan | 6/8 hot swappable counter rotating fans, supporting N+1 redundancy |
| Power | 4 hot swappable power modules can be configured, supporting N+N/N+M redundancy, with optional 2000W platinum/titanium power supply, 2600W platinum power supply, and 3000W titanium power supply |
| Manage | The iBMC chip integrates a dedicated management GE network port, providing comprehensive fault diagnosis, automated operation and maintenance, hardware security reinforcement and other management features. IBMC supports standard interfaces such as Redfish, SNMP, IPMI2.0, etc; Provide a remote management interface based on HTML5/VNC KVM; Support out of band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity FusionDirector management software is optional, providing advanced management features such as five major intelligences to achieve intelligent, automated, visualized, and refined management throughout the entire lifecycle |
| Operating system | Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Ubuntu, openEuler and other compatible systems. |
| Security features | Support power on password, administrator password TPM 2.0, Safety features such as safety panel, safety start, and lid opening detection |
| Operation temperature | 5 ºC to 35 ºC (41 ºF to 95 ºF) (compliant with ASHRAE A3 and A4 standards) |
| Product Certification | CE, UL, CCC, FCC, VCCI, RoHS |
| Installation package | Support L-shaped slide, extendable slide, and rail support |
| Size | 175mm×447mm×898mm |
FusionServer G5500 V7 (hereinafter referred to as G5500 V7) is a new generation 4U2 AI server that supports up to 10 dual wide GPU cards and has the expansion capability of 4 PCIe standard cards and 3 OCP cards. It achieves ultra large capacity or ultra high speed storage by supporting 24 3.5-inch hard drives or 12 NVMe SSD drives.
G5500 V7 has the advantages of high performance, flexible architecture, high reliability, easy deployment, and easy management.
G5500 V7 is for AI training, AI reasoning HPC, Accelerate applications such as image and video analysis and databases, supporting deployment in both enterprise and public clouds.
We are specialized in computer hardware sales and network platform construction and maintenance of IT enterprises. Our main products are Dell, HP, IBM, Lenovo, Huawei, convinced, Youyou mail and other products. We have a sound sales network system, stable commodity supply channels, and an excellent technical support team. Based on this advantage, our business has expanded rapidly, and now we have become an excellent server system integrator and solution provider for a number of well-known enterprises and institutions at home and abroad.
Since our inception, we have established a good customer relationship maintenance system and support system. Committed to the real price of genuine market competition, active open cooperation, and establishing strong supplier partnerships. In the competitive market environment, we align with the "Customer first, honest and pragmatic, service first" business philosophy to strengthen the quality of products and thoughtful service to win trust. We wish our professional quality and first-class service can be accepted and introduced by you and your enterprise.
Yes, all our products are brand new from the original factory, unless second-hand products are specifically requested.
Yes, we maintain a well-stocked warehouse, and you are always welcome to inspect the goods.
As a senior agent of the brand, our pricing is highly competitive. We offer optimized discounts for bulk orders.
Typically 1-3 working days after payment confirmation.
Different products come with different warranties, which can be extended up to five years upon request.
We accept orders starting from a single set.
