Vertex AI Server
1 / 5
| Model | Custom/OEM |
| Form Factor | 4U rack server |
| CPU | Support 2 fourth/fifth generation Intel® Xeon® Scalable processors, TDP 350W |
| Memory | Supports 32 DDR5 memory slots, up to 5600MHz Supports RDIMM, 3DS RDIMM, and up to 8TB of memory |
| GPU | Supports up to 10 dual width GPUs |
| Local Storage | Integrated 6Gb/s onboard SATA, optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID card Support VMD and VROC |
| I/O ports |
Front end: 2 USB 3.0 ports, 1 VGA port Rear: 1 serial port, 2 USB 3.0 ports, 1 VGA port, 1 RJ45 management port |
| Fan | 8 8056 high-speed fans, hot swappable, N+1 redundant Support optional rear fan module |
| Power | Four CRPS power modules can be configured, supporting hot swapping and 2+2/3+1/1+1 redundancy modes. Optional 1600W/2000W/2400W/2700W, Platinum level power supply |
| Manage | Integrated BMC management chip AST2600, supporting IPMI2.0, Redfish, SOL, KVM, virtual media and other functions |
| Safety | Optional TPM/TCM security module, chassis open cover intrusion detection, locked chassis cover (tool free) Support BIOS/BMC dual flash redundancy design |
| Port | Front end: 2 USB 3.0 ports, 1 VGA port Rear: 1 serial port, 2 USB 3.0 ports, 1 VGA port, 1 RJ45 management port |
| Size |
4U standard rack mounted 3.5" hard drive chassis size: width 448mm x height 175mm x depth 822mm (including hanging ears 842mm) 2.5" hard drive chassis size: width 448mm x height 175mm x depth 772mm (including hanging ears 792mm) |
| Operation temperature | Operating temperature: 5 ºC - 35 ºC Storage temperature: -40 ºC - 65 ºC |
| Humidity | Relative humidity at work: 8% to 90% (without condensation). Storage relative humidity: 5% to 95% (non condensing) |
| Operating system support | Support Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, Debian. Waiting for mainstream operating systems |
The new generation flagship 4U dual 8-card GPU server product, based on the fourth/fifth generation Intel® Xeon® Scalable processor, fully upgraded in CPU, GPU, and I/O specifications, supporting various mainstream AI acceleration cards in the industry, with excellent performance, flexible architecture, strong scalability, rich configuration, and high reliability, suitable for applications such as artificial intelligence, high-performance computing, and data analysis.
Yes, all our products are brand new from the original factory. In addition to second-hand products you specifically want.
Yes, we have a warehouse, and you are always welcome to visit and inspect the goods.
As the senior agent of this brand, our discount is very advantageous. As long as you have a large amount, we can give you the best discount.
1-3 working days after your payment.
Our different products have different warranty, if necessary, we can extend the warranty to five years.
We accept orders from 1 set, please feel free to inquire.
