Vertex AI Server
1 / 5
| Model | Custom/OEM |
| Form Factor | 4U rack server |
| Processor | 2 AMD EPYC™ 9004/9005 series processors, maximum power 500W |
| Gpu | 8/10 GPU |
| Memory | 24 DDR5 memory slots, each CPU supports 12 memory channels, supporting up to 6400MT/s Supports RDIMM/3DS RDIMM |
| Local Storage | Supports 8/12 3.5-inch hard drives Supports 8/16/24 2.5-inch hard drives Supports optional 2/4 U.2 NVMe SSDs, 1 M.2 SSD, 2280&22110 sizes, supports PCIe 3.0 x4 |
| PCLs | Option 1: Supports 8 full height, full length, dual width PCIe 5.0 GPU cards. Supports up to 1 PCIe 5.0 x16 + 2 PCIe 5.0 x8 except for 8GPU Solution. Option 2: Supports 8 full height, full length, dual width PCIe 4.0 GPU cards. Supports up to 1 PCIe 4.0 x16 + 2 PCIe 4.0 x8 except for 8GPU configuration. Compatible with 10 GPU card configurations (supports 5 PCIe 5.0 x16 in addition to 8GPU). |
| Fan | 4 hot swappable fan modules, supporting N+1 redundancy, intelligent speed regulation, and abnormal alarm |
| Power | Four power modules can be configured, supporting N+1 redundancy and hot plugging. Optional 220V AC/240V DC/336V DC/-48V DC input. Optional 1600W/2000W/2400W/2700W/3000W high-efficiency platinum power supply. |
| Manage | Integrated BMC management chip, supporting IPMI2.0, Redfish, SOL, KVM, virtual media and other functions |
| Safety | Optional TPM/TCM security module, chassis open cover intrusion detection, locked chassis top cover |
| Port | Front end: 1 VGA, 2 USB 3.0. Rear: 1 VGA, 2 USB 3.0, 1 RJ45 management network port, 1 COM |
| Size | 2.5" hard drive chassis size: width 448 x height 175 x depth 772mm (including hanging ears 792mm). 3.5" hard drive chassis size: width 448 x height 175 x depth 822mm (including hanging ears 842mm). |
| Operation temperature | 0ºC - 35ºC (without direct lighting) |
| Humidity | 10% - 85% |
| Operating system support | Support mainstream operating systems such as Microsoft Windows Server, Red Hat Enterprise Linux, Ubuntu Linux, CentOS, etc |
4U dual AI server product, based on AMD EPYC™ The 9004/9005 series processors are built with comprehensive upgrades in CPU, GPU, and I/O specifications, featuring high computing power, strong scalability, rich configuration, and high reliability. They are suitable for applications such as artificial intelligence, high-performance computing, and data analysis.
Supports 2 AMD EPYCs™ The 9004/9005 series processors adopt the Zen 5 new core architecture, 5nm new process, support up to 500W models, and have strong computing performance. Supports 24 DDR5 memories with a maximum frequency of 6400MT/s, providing excellent memory bandwidth and capacity.
Decoupling design of hardware modules enables flexible configuration of computing, storage, and networking to meet different business needs. Supports flexible selection of 3.5" or 2.5" hard drive modules, supporting up to 8 U.2 NVMe. Supports 10 full height, full length, and dual width GPU cards, supporting training and inference GPUs. Support OCP NIC 3.0 network expansion, optional expansion of 4 × 1GbE/2 × 10Gb SFP+/4 × 10Gb SFP+/2 × 25Gb SFP28 network configuration.
The key components of the system are designed with redundancy and hot swapping, and support tool free disassembly and assembly to improve fault maintenance efficiency and enhance system availability. Integrated intelligent management chip, providing an open management platform, supporting multiple management protocols such as IPMI2.0, Redfish, SNMP, etc. Supports various management functions such as remote KVM, virtual media, critical component status monitoring, and abnormal alarms, achieving comprehensive remote system level intelligent management.
We are specialized in computer hardware sales and network platform construction and maintenance of IT enterprises. The company's main products are Dell, HP, IBM, Lenovo, Huawei, convinced, Youyou mail and other products. The company has a sound sales network system, stable commodity supply channels, and an excellent technical support team. Based on this advantage, the company's business has expanded rapidly, and now has become an excellent server system integrator and solution provider for a number of well-known enterprises and institutions. Since its inception, we have established a good customer relationship maintenance system and support system. Committed to the real price of genuine market competition, active open cooperation, establishing strong supplier partnerships. In the competitive market environment, we operate in line with the "Customer first, honest and pragmatic, service first" business philosophy, striving to strengthen the quality of products and thoughtful service to win trust. We wish our professional quality and first-class service can be accepted and introduced by you and your enterprise.
Yes, all our products are brand new from the original factory, in addition to second-hand products you specifically want.
As the senior agent of this brand, our discount is very advantageous. As long as you have a large amount, we can give you the best discount.
Generally 1-3 working days after your payment is received.
Our different products have different warranty terms. If necessary, we can extend the warranty up to five years.
We accept orders from 1 set, please feel free to inquire.
We support standard payment methods including T/T, Western Union, and online trade platforms.
