The company has 10 years of distribution experience. It is a high-tech enterprise integrating system integration, IT consulting and providing professional IT services. It is the core agent and business partner of Huawei, Lenovo, Dell, and IBM. We look forward to cooperating with you. We can customize freely according to your needs!
| Model | Custom/OEM |
| Form Factor | 4U rack server |
| Processor | Holding two fourth or fifth generation Intel Xeon Scalable processor, supporting up to 350W |
| RAID | Optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID card |
| GPU | Supports 8 600W GPUs, optional support for fan card or turbo card |
| Memory | Supports 32 DDR5 memory, up to 5600MHz, RDIMM/3DS RDIMM |
| Local Storage | Supports 8 3.5 "/2.5" SAS/SATA hard drives (optional support for 2/4 U.2 NVMe SSDs) Supports 2 onboard M.2 (SATA 3.0/PCIe 4.0 x4, 2280&2210) |
| PCLs | Supports up to 11 standard PCIe 5.0 slots / Optional support for 1 OCP 3.0 network card, PCIe 5.0 x8 / Optional 4 × 1GbE/2 × 10Gb SFP+/2 × 25Gb SFP28 |
| Fan | Heat dissipation optimization design, CPU computing module and GPU computing module are isolated for heat dissipation, and the fan supports hot plugging and intelligent speed regulation |
| Power | Optional 4 CRPS power supplies, supporting 2+2/3+1 redundancy; Optional 6 CRPS power supplies, supporting 3+3 redundancy; Optional 2000W/2700W/3200W/3600W power modules; The power module supports hot swapping |
| Manage | Integrated BMC management chip AST2600, supporting IPMI2.0, Redfish, SOL, KVM, virtual media and other functions. Provide 1 1Gbps RJ45 dedicated management port |
| Safety | Optional TPM/TCM security module, chassis open cover intrusion detection, locked chassis cover (tool free) Support BIOS/BMC dual flash redundancy design |
| Port | Front end: 2 USB 3.0 ports, 1 VGA port. Rear: 1 serial port, 2 USB 3.0 ports, 1 VGA port, 1 RJ45 management port |
| Size | Width 448mm x Height 306mm x Depth 896mm |
| Operation temperature | Operating temperature: 5 ºC - 35 ºC. Storage temperature: -40 ºC - 65 ºC |
| Humidity | Relative humidity at work: 8% to 90% (without condensation). Storage relative humidity: 5% to 95% (non condensing) |
| Operating system support | Support mainstream operating systems such as Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Ubuntu, etc |
Widely used GPU servers that support fourth or fifth generation Intel Xeon Scalable processor, supporting 8 600W GPUs, with excellent performance, strong scalability, and high reliability, suitable for various application scenarios such as artificial intelligence, large model inference, graphics rendering, cloud gaming, etc.
Adopting Intel Xeon 4th/5th generation processor platform, the CPU computing power, PCIe speed, and memory bandwidth have been fully upgraded, fully unleashing GPU computing power. Supports 8 600W GPUs, each card supports PCIe 5.0 x16, providing efficient heterogeneous computing power. CPU-GPU direct design, efficient and low latency, significantly improves data transmission efficiency compared to PCIe Switch architecture.
Super compatibility, optional support for fan card or turbo card. Supports 8 quad width fan cards or 8 dual width turbine cards.
Supports up to 11 PCIe 5.0 standard slots, with multiple PCIe configurations to choose from. Optional 1 OCP 3.0 network card, multiple speed options available. Supports 8 3.5 "/2.5" SAS/SATA hard drives, optional support for 2/4 NVMe SSDs, balancing large capacity and high-performance local storage.
The key components of the system are designed with redundancy and hot swapping, and support tool free disassembly and assembly to improve fault maintenance efficiency and enhance system availability. Integrated intelligent management chip, providing an open management platform, supporting multiple management protocols such as IPMI2.0, Redfish, SNMP, etc. Supports various management functions such as KVM, virtual media, critical component status monitoring, and abnormal alarms, with comprehensive remote system level intelligent management capabilities.
We are specialized in computer hardware sales and network platform construction and maintenance of IT enterprises. Our main products are Dell, HP, IBM, Lenovo, Huawei, convinced, Youyou mail and other products. We have a sound sales network system, stable commodity supply channels, and an excellent technical support team. Based on this advantage, our business has expanded rapidly, and now we have become an excellent server system integrator and solution provider for a number of well-known enterprises and institutions at home and abroad. Since inception, we have established a good customer relationship maintenance system and support system. Committed to the real price of genuine market competition, active open cooperation, and establishing strong supplier partnerships. In the competitive market environment, we operate in line with the "Customer first, honest and pragmatic, service first" business philosophy to strengthen the quality of products and thoughtful service to win trust in society. We wish our professional quality and first-class service can be accepted and introduced by you and your enterprise.
